The halogen fast moisture analyzer is a new type of fast moisture analyzer. Its annular halogen heater ensures that the sample is uniformly heated during the high temperature testing process, so that the surface of the sample is not easily damaged and dried quickly. During the drying process, the moisture analyzer continuously measures and immediately displays the lost moisture content of the sample. After the drying process is completed, the final moisture content determined is locked. Show. Compared with the international oven heating method, the test results have good consistency and substitution, and the detection efficiency is much higher than that of oven heating method. Normally, it takes only a few 4-5 minutes for the sample to complete the determination. The instrument is simple to operate and accurate to test. The display part adopts a large screen touch screen. The display value is clear and visible. It can display water value, initial value of sample, final value, determination time, initial value of temperature and final value of temperature respectively. It also has the function of connecting with computer and printer. The moisture meter is widely used in all industries requiring rapid determination of water content, such as medicine, grain, feed, seeds, dehydrated vegetables, tobacco, chemical industry, tea, food, meat, agriculture and forestry, paper making, rubber, plastics, textile and other industries in raw materials, intermediates, finished product samples testing and data printing.

Model



HYG-10



HYG-10A



HYG-16



HYG-16A



HYG-20A



Range



50g



50g



120g



120g



120g



Weighing readability



0.01g



0.005g



0.005g



0.002g



0.001g



Water readability



0.02%



0.01%



Moisture Accuracy



Less than 0.5%



Sample weight



More than 10g)



Less than 0.5% (sample weight (> 2g)



Temperature control tolerance



+ 1 c



Heating temperature range



60 to 200 degrees Celsius (adjusted at 1 degrees Celsius)



Heating time range



0-99 minutes (1 minute) adjustment



Terminal control



Timing automatic manual



Result display parameters



Nine species (see Chapter 3.5 for details)



Measuring moisture range



0% to 100%



Sample Disk Size



90mm



communication



Serial port RS232



Appearance size



360 x 215 x 170 mm



Net weight



4.5kg



Heating source



Halogen lamp

The weighing part adopts imported sensors from Germany, which fully guarantees the stability and non-drift of weighing.



Precision casting metal shell, heating part of imported polymer materials, ultra-high temperature moulding, to ensure product performance;



Ring halogen lamp heating, multi-layer stainless steel heating chamber, heating fast and uniform in the testing process, effectively improve the heating efficiency and shorten the working time;



LCD touch display large screen, with multi-button operation, easy to operate, test results at a glance, and optional printer, objective recording of test results, convenient for reference;



RS232 data interface can connect PC and printer, and can store data inside.
