1. 320 *240 LCD, high-speed thermal printer.
2. High-voltage voltage, high-voltage current, low-voltage voltage, low-voltage current four measurement methods, high-precision sensors and high-performance 14-bit AD acquisition chip.
3. Man-machine dialog keyboard operation mode, the whole process of intelligent work, three test modes: manual boost test, continuous boost test and step-by-step boost test.
4. Various boost speeds can be selected to meet the requirements of boost and boost speeds in different tests.
5. Real-time display of high-voltage voltage, high-voltage current, low-voltage voltage voltage, low-voltage current, time and withstand voltage results, showing intuitive and clear.
6. Perfect over-voltage and over-current protection, arbitrarily set the maximum voltage, high-voltage current upper limit, low-voltage current upper limit and time.
7. Manual boost test, keyboard simulation to achieve point-up, point-down, timing, closing, opening, timing and other functions.
8. Continuous boost test, after setting the maximum voltage and time, one-stop test is completed.
9. Step-by-step boost test can set the starting voltage, automatically calculate or manually set the voltage increment, step-by-step boost test, timing automatic cycle boost to the highest voltage.
10. It has the function of zero-return detection, and can be tested only after the zero-return is confirmed. It is safe and reliable.
11. Approximate voltage regulation algorithm, automatic withstand voltage timing after reaching the set voltage, automatic step-down and return to zero after the end of the timing.
12. When the voltage exceeds the set high voltage current or low voltage current, the output voltage is automatically cut off, the voltage is reduced to zero, and an acoustooptic alarm occurs.
13. The prompt information is convenient for guiding operation, and boosting can only be realized by switching keys, so as to prevent the danger caused by repeated press of one key fatigue operation.
14. During the test, you can press the Cancel button to exit any test. If the test is abnormal, the high voltage output can be cut off by pressing the emergency switch.
15. Excellent hardware and software anti-interference design, a variety of anti-interference means, to adapt to harsh electromagnetic environment.
16. Automatic error diagnosis, easy to find and solve problems.
17. Optional wireless remote control function, remote communication, door interlocking alarm light alarm bell, external voltage divider calibration interface, etc.
